Smart Weight Indicator

The Smart range of Stainless steel digital weight indicators provides a simple but rugged solution where a local display of weight is required. OIML R76 and EN 45501 approval is a standard feature and excellent protection against EMC interference is provided.

Three models are available, with different features at different price points, to cover most requirements. Depending on the chosen model, RS232, RS485 communications, analogue outputs, digital inputs and outputs are available.

Make an enquiry about this excellent IP65 weight indicator.

Multi-range operation and calibration in mV/V (without using real weights) is possible with all versions.

An ATEX version for use in zones 2, 21 and 22 is also available.

Key features:

• OIML R76 and EN 45501:2015 (NAWI) approvals
• Model approval from Legal Metrology Department, Government of India
• Stainless steel construction with IP65 protection
• User friendly configuration and calibration menu
• 7 digit, high brightness, LED display
• High resolution; 100,000 external divisions
• Multi-range for dual range and dual division
• Linearity correction
• RS232, RS485, analogue output options
• Calibration in mV/V is possible (without live weights)
• Operation on 230 VAC or 9-18 VDC

Product conformity:

• 2014/30/EU (EMC Electromagnetic Compatibility)
  • EN 61000-6-3:2007/A1:2011
  • EN 55022 Class B
  • EN 45501:2015 (NAWI)
• 2014/35/EU (Low Voltage Directive)
  • EN 61010-1:2010
• OIML R76
• Model approval from Legal Metrology Department, Government of India
